Suprema X-Station 2

Versatile Time & Attendance and Access Control

Suprema X-Station 2 Proximity & Fingerprint Reader

The Suprema X-Station 2 is a flexible smart terminal that supports various forms of identification, including RFID cards, such as proximity cards, key fobs, and fingerprints. This versatility makes the X-Station 2 suitable for both Time & Attendance and Access Control applications in a wide range of different industries and environments.

The X-Station 2 is available with or without the fingerprint module, giving businesses the flexibility to choose their preferred identification methods. The RFID-only solution also offers a more affordable solution. Don’t hesitate to get in touch with our sales team to learn more about the X-Station 2 options.

Equipped with secure boot process, Open Supervised Device Protocol (OSDP) and cameras for image logs, X-Station 2 enhances security while ensuring user data is protected. The X-Station 2 is easy to self-install, or you could take advantage of our installation services for peace of mind. Using and maintaining the terminal is also a simple process thanks to a host of impressive features such as Power over Ethernet (PoE), intuitive GUI on 4” wide touchscreen, and IP65 rating.

Key Benefits

Suitable for access control and time and attendance application

Max. 500k users, 5 million text logs, 50k image logs

Dust-tight and waterproof IP65 protection

RFID Card Compatibility, Suitable for Proximity Cards and Fobs

Power over Ethernet (PoE) enables convenient installation with less wiring

Operating Temperature -20°C ~ 50°C (-4°F ~ 122°F)

UI and user-friendly operation interface

4 inch IPS color LCD / 480 x 800 pixel

Suprema X-Station 2 – Technical Specification

Size: 82mm(L) x 159mm(W) x 25.9mm(D)

4 inch IPS color LCD / 480 x 800 pixel

Camera: CMOS 2M pixels / 1600 x 1200

USB 2.0 (Host)

IP65 Certified

Power: Voltage: 12 Vdc, Current: Max. 0.8 / Voltage: 24 Vdc, Current: Max. 0.5 A

Ethernet: 10/100 Mbps, auto MDI/MDI-X

Power over Ethernet (PoE) supported

Operating Temperature: -20 ℃ to 50 ℃
